HJ160 Water Jet Pump - High-Performance Marine Propulsion
The HJ160 is a compact, high-thrust water jet propulsion system designed for high-speed marine craft. With a 160 mm impeller delivering up to 500 kg of thrust, it is the ideal propulsion solution for rescue boats, motorboats, yachts, and unmanned surface vessels (USVs).
Key Specifications
| Impeller Diameter | 160 mm |
| Maximum Thrust | 500 kg |
| Matched Power Range | 90 - 200 HP |
| Max Rated Speed | 6,500 RPM |
| Dry Weight | 30 kg |
| Overall Dimensions | 1,000 × 300 × 270 mm (L×W×H) |
| Water Inlet Size | 510 × 300 × 270 mm (L×W×H) |
Key Advantages
- Shallow Water Capable - No protruding propeller allows operation in water as shallow as 300 mm. Perfect for rivers, lakes, and coastal zones.
- Weed & Debris Resistant - Enclosed intake eliminates fouling from seaweed, fishing nets, and floating debris.
- Exceptional Thrust-to-Weight - 500 kg thrust from a 30 kg unit delivers rapid acceleration and planing.
- Enhanced Safety - No exposed propeller means zero risk to swimmers, divers, or marine life.
- Low Maintenance - Simplified design with easy access to impeller and wear ring.
Applications
High-speed rescue boats . Motorboats . Pleasure yachts . USVs . River & shallow-water craft . Survey & patrol boats
Optional Engine Package
The HJ160 can be paired with a 197 HP Turbocharged Gasoline Engine ($6,180 FOB Qingdao) for a complete propulsion solution. Contact us for details.
